Product details
Core Specifications:
| Print Area | 3200mm |
| Print Height | Max 20mm |
| Resolution | Max 540×1440 dpi |
| Print Speed | Production: 60~90sqm/h |
| Print Head | Konica 1024A(6PL) |
| Konica 1024i(13PL) | |
| Head Quantity | 4~48pcs |
| Ink Colors | CMYK+LC+LM+W |
System Specifications:
| Curing Method | UV LED |
| File Formats | TIFF, JPEG, EPS, PDF |
| RIP Software | SAI/ONYX/Caldera |
| Power Requirements | AC220V 50/60HZ 17.5KW 80A |
| Environment | Temperature: 20°C~28°C Humidity: 40%~60% |
| Ink Tank Capacity | 5L |
| Dimensions | 6600mm × 2250mm × 2250mm
(with automatic loader: 6600mm × 3000mm × 2500mm) |
| Weight | 6500kg |
