Product details
| Feature | SG-B720II/B720IIP | SG-B1400II/B1400IIP | SG-B1800II/B1800IIP |
| Maximum sheet size | 720mm | 1400mm | 1800mm |
| Maximum cutting size | 610mm | 1295mm | 1695mm |
| Minimum cutting character | About 5mm² | About 5mm² | About 5mm² |
| Mechanical resolution | 0.02mm | 0.02mm | 0.02mm |
| Repeat precision | 0.082mm | 0.082mm | 0.082mm |
| Maximum linear cutting speed | 960mm/s | 960mm/s | 960mm/s |
| Maximum cutting force | 750g | 750g | 750g |
| Cutting control system | DC Servo | DC Servo | DC Servo |
| Motor speed | 0-3000RPM | 0-3000RPM | 0-3000RPM |
| CPU | 64-DSP | 64-DSP | 64-DSP |
| Package dimensions | 1030×350×490mm | 1710×350×490mm | 2100×400×550mm |
| Actual dimensions | 930×250×260mm | 1610×250×260mm | 2010×250×260mm |
| Gross/Net weight | 27±10kg/25±10kg | 42±10kg/35±10kg | 68±10kg/47±10kg |
| Software and compatibility | — | — | — |
| Connectivity | USB/RS-232 | USB/RS-232 | USB/RS-232 |
| Software and compatibility | Dragon Cut (Windows 7,8,10 USB direct connection), Corel Draw/Illustrator Plug-in (SD direct connection) | Dragon Cut (Windows 7,8,10 USB direct connection), Corel Draw/Illustrator Plug-in (SD direct connection) | Dragon Cut (Windows 7,8,10 USB direct connection), Corel Draw/Illustrator Plug-in (SD direct connection) |
| Power and working environment requirements | — | — | — |
| Power source | 100V~240V, 50/60Hz | 100V~240V, 50/60Hz | 100V~240V, 50/60Hz |
| Power | 150W | 150W | 150W |
| Operation environment | Temperature +5°C to +35°C (41-95°F), Humidity 30%-75% (Non-condensing) | Temperature +5°C to +35°C (41-95°F), Humidity 30%-75% (Non-condensing) | Temperature +5°C to +35°C (41-95°F), Humidity 30%-75% (Non-condensing) |
| Stand & pocket | Included | Included | Included |
