Product details
| Model: | NL-CO2W10 / NL-CO2W30 / NL-CO2W50 / NL-CO2W100 |
| Laser Power: | 10W / 30W / 50W / 100W |
| Laser Wavelength: | 10.64um |
| Laser Repitition Frequency: | ≤20KHZ / ≤25KHZ / ≤100KHZ |
| Marking Depth: | ≤2mm / ≤5mm / ≤8mm |
| Minimum Line Width: | 0.05mm / 0.10mm / 0.15mm |
| Minimum Character Size: | 0.20mm / 0.40mm / 0.50mm |
| Repetition Accuracy: | ±0.01mm |
| Marking Range: | 70x70mm / 140x140mm / 140x140mm / 300x300mm |
| Marking Speed: | ≤7000mm/s |
| Total Machine Power: | 500W / 1.2KW / 2KW / 4KW |
| Power Requirements: | 220V/50Hz/3.5A, 220V/Hz/8A, 220V/Hz/11A, 220V/Hz/20A |
| Cooling Method: | AIR / WATER |
