Product details
Software support:
DXF/PLT files input, support CAD, TYPE3, CRELDREW, ILLUSTRATOR, etc
Technical Parameter:
| Power Supply: | AC220V 50Hz |
| Power: | 2.2KW |
| Compressed Air: | 0.4~06MPa |
| Control Axis Quantity: | 4 Axis |
| Min. Bending Radius: | R7mm |
| Min. Distance Between Interior Angle And Exterior Angle: | 2mm |
| Bending Distance From Start: | 3mm |
| Applied Material | Stainless Steel, Galvanized Sheet, Aluminium Coil |
| Material Thickness: | 0.5~1.0mm |
| Material Feeding Method: | Alternate Feeding |
| Processing Height: | 20~115mm |
| Servo Motor: | 2Pcs |
| Step Motor: | 2Pcs |
| N.W./G.W.: | 400Kgs / 480Kgs |
| Dimension: | 1450(L) x 820(W) x 1550(H) mm |
